MSI A520M PRO

Chipset: AMD A520

Rozmerový formát: M-ATX Form Factor (244 mm x 210 mm)

Podpora pre procesory: AMD Ryzen™ 5000 & 3000 Series desktop processors

Pätica procesora: AM4

Pozícia na pamäti: 2x DDR4 DIMM

Podpora pre pamäte:

*1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC

*2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE

Max.veľkosť operačnej pamäte: 64 GB

Podpora pre pamäte typu: DDR4

*Dual channel memory architecture

*Supports non-ECC UDIMM memory

*Supports ECC UDIMM memory (non-ECC mode)

*Supports un-buffered memory

Grafická karta: Integrated Graphics Processor (na základe procesora)

Zvuková karta:

*Realtek® ALC892/ALC897 Codec

Sieťová karta:

*Realtek® RTL8111H LAN controller

Rozširujúce sloty:

*1x PCIe x16 slot (PCI_E2)

*2x PCIe 3.0 x1 slots

RAID radič: 0, 1, 10

SATA:

*4x SATA 6Gb/s ports

M.2:

*1x M.2 slot (Key M) (from AMD Processor)

USB:

* zadné USB porty ( celkom 6 )

*2x USB 2.0 ports

*4x USB 3.2 Gen 1 5Gbps Type-A ports

* predné USB porty ( celkom 6 )

*2x USB 3.2 Gen 1 5Gbps ports

*4x USB 2.0 ports

Interné porty:

*1x 24-pin ATX main power connector

*1x 8-pin ATX 12V power connector

*4x SATA 6Gb/s konektory

*1x Serial port connector

*1x M.2 slot (M-Key)

*1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)

*2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

*1x 4-pin CPU fan connector

*1x 4-pin system fan connector

*1x Front panel audio connector

*2x System panel connectors

*1x Chassis Intrusion connector

*1x 4-pin RGB LED connector

*1x 3-pin RAINBOW LED connector

*1x TPM module connector

*1x Clear CMOS jumper

Externé porty:

*VGA

*Keyboard / Mouse

*1x LAN port

*HDMI

*DisplayPort

*2x USB 2.0 Ports

*4x USB 3.2 Gen 1 5Gbps Type-A

*Audio Connectors

Stránka výrobcu: https://www.msi.com/Motherboard/A520M-PRO
