MOTHERBOARD Form factor Mini ITX, mATX, µATX, ATX, SSI CEB, SSI EEB, eATX max. Motherboard size 305mm x 330mm (12" x 13") INSTALLATION DIMENSIONS Height CPU cooler (max.) 150mm Length graphics card (max.) 330mm DRIVE BAYS 5.25" external 3xą 3.5" external 3.5" internal 11xą 2.5" internal 4xą ą can vary by using several mounting options FRONT CONNECTORS USB 3.0 2x USB 2.0 POWER SUPPLY PS2/mini redundant PSU ATX PSU FAN MOUNTING OPTION Front 2x 120mm (serial, Molex connector) and 6x 40mm (optional, behind the 5.25"brackets) Rear 2x 80mm (serial, 3pin connector) CONTROLS & LED Controls Power-Switch Reset-Button LED Power HDD Activity 3x Network Activity Alert OTHER DATA Dimensions (h/w/d) 177.8 x 485 x 595mm Material 1.0-1.2mm Steel Warranty 24 months SCOPE OF DELIVERY & FEATURES Scope of delivery Case Retail packaging Screw Set Mounting rails for 3.5" hard drives Mounting frame for redundant power supplies Features 7 slot openings 2x 120mm and 2x 80mm fan included Up to 6x 40mm fan optional mountable Lid with snap lock LOGISTICAL DATA Shipping Unit 1 Pcs EU palett 15 Pcs Weight net = 11.46kgs gross = 13.71kgs Item number 88887304 EAN-Code 4260455645935
