General
Product Dimension (W × H × D)
235.1 mm X 140.2 mm X 158.2 mm
Package Dimension (W × H × D)
320mm*280mm*85mm
Net Weight
0.38 kg
Packing List
3000Mbps Wi-Fi6 Router x 1

Power Supply Adapter × 1

CAT5e Network Cable × 1

Quick Start Guide × 1

Regulatory Compliance and Safety Information × 1

Packing Method
Single pack
Working Temperature
0 ? to 40 ? (32 ? to 104 ?)
Working Humidity
10% to 90% RH non-condensing
Storage Temperature
-40 ? to 70 ? (-40 ? to 158 ?)
Storage Humidity
20 ? to 70 ? (-68 ? to 158 ?)
Installation Mode
Desktop installation
Max. Power Consumption
?12 W
Gross Weight
0.82kg
Wireless Parameter
Data Rate
3000Mbps Wi-Fi6 Router x 1

Power Supply Adapter × 1

CAT5e Network Cable × 1

Quick Start Guide × 1

Regulatory Compliance and Safety Information × 1

Wireless Standard
IEEE 802.11a/n/ac/ax @5 GHz

IEEE 802.11b/g/n/ax @2.4 GHz

Transmitting Power
CE:

<20dBm(2.4GHz)

<23dBm(5GHz)

Wireless Performance
MU-MIMO supported

TxBeamforming supported

OFDMA supported

Receiving Sensitivity
5GHz:

-88dBm@HE80-MCS0

-58dBm@HE80-MCS11

2.4GHz:

-92dBm@HT40-MCS0

-62dBm@HT40-MCS7

Antenna
2.4 GHz antenna × 2, 5 GHz antennas × 3
Hardware Parameter
Network Interface
1 × 10/100/1000 Mbps Adaptive WAN Port

3 × 10/100/1000 Mbps Adaptive LAN Ports

LED Indicator
LED indicator
Reset
Reset button
Power Supply Method
Power Supply Adapter
Power Specifications
DC 12 V, 1 A
Software Function
Application function
Router Mode , Repeater Mode, AP Mode

TR069 settings supported

DHCP Server supported

Guest Network Configuration supported

Signal Adjustment supported

WiFi Schedule supported

IPv6 supported

VLAN supported

VPN supported

DDNS supported

Firewall supported

terminal management

WAN adaptive supported

Security Mode
WPA-PSK, WPA2-PSK, WPA and WPA2, WPA2 and WPA3 supported
Security Mechanism
Hide SSID,Firewall
Management Method
Web, HPP, HC
Upgrade
Web, App Update and Upgrade
System Log
System log
Roaming
802.11k/v
