Chipset: AMD B450

Rozmerový formát: mATX Form Factor (226 mm x 221 mm)

Podpora pre procesory: 3rd/2nd/1st Gen AMD Ryzén™/2nd a 1st Gen AMD Ryzén™ s Radeon™ Vega Graphics/Athlon™ s Radeon™ Vega Graphics Processors

Pätica procesora: AM4

Pozícia na pamäti: 2x DDR4 DIMM

Podpora pre pamäte: 4400(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3300(OC)/3200(OC)/3000(OC)/2933(OC)/2300 Un-buffered Memory

Max.veľkosť operačnej pamäte: 64 GB

Podpora pre pamäte typu: DDR4

*Dual Channel Memory Architecture

*ECC Memory (ECC mode) support varies by CPU

Grafické výstupy:

*Integrated Graphics Processor (na základe procesorov 2. a 1. generácie AMD s Radeon Grpahics/Athlon)

Zvuková karta:

*Realtek 7.1-Channel High Definition Audio CODEC

Sieťová karta:

*Realtek® RTL8111H

Rozširujúce sloty:

* 3rd/2nd/1st Gen AMD Ryzen™ Processors

*1x PCIe 3.0 x16 (x16 mode)

* 2nd a 1st Gen AMD Ryzen™ s Radeon™ Vega Graphics Processors

*1x PCIe 3.0 x16 (x8 mode)

* AMD Athlon™ s Radeon™ Vega Graphics Processors

*1x PCIe 3.0 x16 (x4 mode)

* AMD B450 chipset

*2x PCIe 2.0 x1

RAID radič: 0, 1, 10

SATA:

*4x SATA 6Gb/s ports

M.2:

*1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)

USB:

* zadné USB porty ( celkom 6 )

*4x USB 3.2 Gen 1 port(s)(4 x Type-A)

* 2x USB 2.0 port(s)(2 x Type-A)

* predné USB porty ( celkom 6 )

*2x USB 3.2 Gen 1 port(s)

*4x USB 2.0 port(s)

Interné porty:

*1x CPU Fan connector(s) (1 x 4 -pin)

*1x Chassis Fan connector(s) (1 x 4 -pin)

*1x USB 3.2 Gen 1(up to 5Gbps) konektor(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin)

*2x USB 2.0 konektor(s) support(s) additional 4 USB 2.0 port(s)

*1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)

*1x SPI TPM header

*1x COM port(s) connector(s)

*4x SATA 6Gb/s connector(s)

*1x S/PDIF out header(s)

*1x 24-pin EATX Power connector(s)

*1x 8-pin ATX 12V Power connector(s)

*1x Front panel audio konektor(s) (AAFP)

*1x System panel(s)

*1x Clear CMOS jumper(s)

*1x COM port header

*1x Speaker connector

Externé porty:

*1x PS/2 klávesnica/mouse combo port(s)

*1x DVI-D

*1x D-Sub

*1x HDMI

*1x LAN (RJ45) port(s)

*4x USB 3.2 Gen 1 (blue) Type-A

*2x USB 2.0

*3x Audio jack(s)

*1x BIOS FlashBack™ Button(s)

Obsah balenia:

*User's manual

*I/O Shield

*2x SATA 6Gb/s cable(s)

*1x M.2 Anchor

*1x Supporting DVD

BIOS: 256 Mb Flash ROM, UEFI AMI BIOS

Stránka výrobcu: https://www.asus.com/Motherboards/PRIME-B450M-K-II

https://www.asus.com/microsite/motherboard/ASUS-motherboards-Win11-ready/

https://www.asus.com/support/FAQ/1046215
